Profile 8 80x40, natural

Profile length: Cut length
Profile 8 80x40, natural
3D
Click and move
spatial.openArView
spatial.tapToPlaceTheObject
spatial.moveTheDeviceToStart
Profile 8 80x40, natural
Profile 8 80x40, natural
Profile 8 80x40, natural
Profile 8 80x40, natural
Profile 8 80x40, natural
Quantity Unit price
To 16pcs
€69.07
From 17pcs
€512.88

Profile length
Allowed range: 20 mm to 6000 mm, step size: 1 mm.
PDF-Datasheet
Product number: PI-1424 SZ
Manufacturer: Maunsystem GmbH
Manufacturer number: 1000164
Weight: 24.16 kg

Description

Product information "Profile 8 80x40, natural"

Profiles 8 are suitable for assemblies of all kinds. Due to the different profile geometries, the material requirements can be adapted to the application. The grooves and the core holes of the profiles 8 are designed for M8 screws.
Cut to size max. 6000 mm

Compatible with item 0.0.621.00

Details

  • Finish natural
  •  ESD ESD-safe = Ja
  •  Area A = 15,13 cm2
  •  Area moment of inertia Torsion It = 22,7 cm4
  •  Area moment of inertia um x-axis Ix = 7,83 cm4
  •  Area moment of inertia um y-axis Iy = 1.420,95 cm4
  •  Weight spec. Length [kg/m] m = 4,1 kg/m
  •  Delivery unit Cut to length max. 6000 mm
  •  Material Al, anodised
  •  Section modulus um x-axis Wx = 4,69 cm3
  •  Section modulus um y-axis Wy = 84,04 cm3
Anodised: E6EV1 10-15 µm silver
Colour: natural
Compatible with: item
Contour: Rectangular
Delivery unit: Cuts
Material: Al Mg Si 0.5 F25, artificially aged
Part type : Shelves
Profile length: Cut length
Series: Series 8, Workstation systems
Tolerances: EN 12020-2
