Profile 5 80x14, natural
Profile length:
Cut length
Maunsystem GmbH
Loading...
€23.86*
| Accessories total price | €0.00 |
accessories
Accessories total price
€23.86 *
Product number:
PI-4080 SZ
Manufacturer:
Maunsystem GmbH
Manufacturer number:
1006763
Weight:
1.79 kg
Product information "Profile 5 80x14, natural"
The compact design of Profiles 5 makes them particularly suitable for small and weight-optimised assemblies. The grooves and core holes of Profiles 5 are designed for M5 screws.
Cut to size max. 6000 mm
Cut to size max. 6000 mm
Compatible with item 0.0.370.85
Details
lx 1,11 cm4
ly 40,69 cm4
wx 1,54 cm3
wy 10,17 cm3
Profilfläche 6,64 cm2
Gewicht 1,79 kg/m
ly 40,69 cm4
wx 1,54 cm3
wy 10,17 cm3
Profilfläche 6,64 cm2
Gewicht 1,79 kg/m
Step-Datei
Download| Anodised: | E6EV1 10-15 µm silver |
|---|---|
| Colour: | natural |
| Compatible with: | item |
| Contour: | Rectangular |
| Delivery unit: | Cuts |
| Execution: | heavy |
| Groove shape: | Open grooves |
| Material: | Al Mg Si 0.5 F25, artificially aged |
| Nutauszugskraft: | F=500 N |
| Profile length: | Cut length |
| Series: | Series 5 |
| Size: | 80x14 mm |
| Tolerances: | EN 12020-2 |
| Breite Profil: | 80 mm |
| Höhe Profil: | 14 mm |
