Profile 5 20x10, natural
Profile length:
Cut length
Maunsystem GmbH
Loading...
€6.07*
| Accessories total price | €0.00 |
accessories
Accessories total price
€6.07 *
Product number:
PI-4010 SZ
Manufacturer:
Maunsystem GmbH
Manufacturer number:
1021961
Weight:
2.1 kg
Product information "Profile 5 20x10, natural"
The compact design of Profiles 5 makes them particularly suitable for small and weight-optimised assemblies. The grooves and core holes of Profiles 5 are designed for M5 screws.
Cut to size max. 6000 mm
Cut to size max. 6000 mm
Compatible with item 0.0.391.02
Details
x   0,53 cm4
ly   0,12 cm4
wx   0,53 cm3
wy   0,22 cm3
Profilfläche   1,29 cm2
Gewicht   0,35 kg/mÂ
ly   0,12 cm4
wx   0,53 cm3
wy   0,22 cm3
Profilfläche   1,29 cm2
Gewicht   0,35 kg/mÂ
Step-Datei
Download| Colour: | natural |
|---|---|
| Compatible with: | item |
| Contour: | Rectangular |
| Delivery unit: | Cuts |
| Execution: | heavy |
| Groove shape: | Open grooves |
| Nutauszugskraft: | F=500 N |
| Profile length: | Cut length |
| Series: | Series 5 |
| Size: | 20x10 mm |
| Breite Profil: | 20 mm |
| Höhe Profil: | 10 mm |
