Profile 45x90 natural-10
Profile length:
6000 mm bar
Maunsystem GmbH
Loading...
€265.08*
| Accessories total price | €0.00 |
Below you will find matching articles
Accessories total price
€265.08 *
Product number:
PB-1250 SN6000
Manufacturer:
Maunsystem GmbH
Manufacturer number:
1001662
Length:
6000 mm
Weight:
24.713 kg
Description
Product information " Profile 45x90 natural-10 "
The profiles in pitch 45 with groove 10 are suitable for assemblies of all kinds. Due to the different profile geometries, the material requirements can be adapted to the application. The grooves are designed for M8 screws.
Compatible with Bosch 3 842 990 300
Compatible with Bosch 3 842 990 300
Compatible with Bosch 3 842 990 300
Details
lx 124,05 cm4
ly 32,25 cm4
wx 27,57 cm3
wy 14,33 cm3
Profile cross-section 15,24 cm2
Weight 4,12 kg/m
ly 32,25 cm4
wx 27,57 cm3
wy 14,33 cm3
Profile cross-section 15,24 cm2
Weight 4,12 kg/m
| Anodised: | E6EV1 10-15 µm silver |
|---|---|
| Colour: | natural |
| Compatible with: | Bosch |
| Contour: | Rectangular |
| Delivery unit: | Rods |
| Execution: | heavy |
| Groove shape: | Open grooves |
| Material: | Al Mg Si 0.5 F25, artificially aged |
| Modular dimension: | Modular dimension 45 |
| Profile height: | 45 mm |
| Profile length: | 6000 mm bar |
| Profile width: | 90 mm |
| Series: | Series 45-10 |
| Size: | 45x90 mm |
| Slot pull-out force: | F=7.000 N |
| Tolerances: | EN 12020-2 |
Skip product gallery
![Cap 45x90-10]( "Cap 45x90-10")
Regular price:
€1.27
![Cap 45x90-10]( "Cap 45x90-10")
AB-3040-S
Cap 45x90-10
Abgerundete Abdeckkappen für die Stirnfläche der verschiedenen Profilquerschnitte.Das Entgraten der Schnittfläche entfällt. Abdeckkappen werden durch Aufschlagen in die Kernbohrungen befestigt.
AB-3040-G
Cap 45x90-10
Abgerundete Abdeckkappen für die Stirnfläche der verschiedenen Profilquerschnitte.Das Entgraten der Schnittfläche entfällt. Abdeckkappen werden durch Aufschlagen in die Kernbohrungen befestigt.
Variants from €1.27
Regular price:
€3.45
Skip product gallery
![Angle Bracket Set 45x45 - 10]( "Angle Bracket Set 45x45 - 10")
Regular price:
€3.57
![Angle Bracket Set 45x45 - 10]( "Angle Bracket Set 45x45 - 10")
![Angle Bracket Set 45x45 - 10]( "Angle Bracket Set 45x45 - 10")
Regular price:
€3.57
![Bolt Connector Set 45, bright zinc-plated-10]( "Bolt Connector Set 45, bright zinc-plated-10")
Regular price:
€3.97
![Bolt Connector Set 90, bright zinc-plated-10]( "Bolt Connector Set 90, bright zinc-plated-10")
Regular price:
€4.54
![Qick Connector 0°, bright zink-plated-10]( "Qick Connector 0°, bright zink-plated-10")
Regular price:
€2.29
![Qick Connector 90°, bright zink-plated-10]( "Qick Connector 90°, bright zink-plated-10")
Regular price:
€2.29
![T- Matic Connector Set, bright zinc-plated-10]( "T- Matic Connector Set, bright zinc-plated-10")
Regular price:
€5.41
ZB-3095-N
Angle Bracket Set 45x45 - 10
Angles are a force-fit and processing wireless connection. These are also used as additional reinforcement of connections and as a fastener for attachments. Integral safety devices for fixing the profile are available. These are removed if necessary.
ZB-3095-W
Angle Bracket Set 45x45 - 10
Angles are a force-fit and processing wireless connection. These are also used as additional reinforcement of connections and as a fastener for attachments. Integral safety devices for fixing the profile are available. These are removed if necessary.
Variants from €3.57
Regular price:
€5.42
ZB-3095-G
Angle Bracket Set 45x45 - 10
Angles are a force-fit and processing wireless connection. These are also used as additional reinforcement of connections and as a fastener for attachments. Integral safety devices for fixing the profile are available. These are removed if necessary.
VB-3015
Bolt Connector Set 45, bright zinc-plated-10
The bolt connector is used to connect two profiles at right angles. It is suitable for very high loads, including torsion. It can be installed in already mounted assemblies.
VB-3030
Bolt Connector Set 90, bright zinc-plated-10
The bolt connector is used to connect two profiles at right angles. It is suitable for very high loads, including torsion. It can be installed in already mounted assemblies.
VB-3050
Qick Connector 0°, bright zink-plated-10
Universal and force-fitting connection of all profiles in a series Can be subsequently slid in the groove. Can be swivelled into the groove Can be retrofitted into an existing construction. Machining only on one profile
VB-3045
Qick Connector 90°, bright zink-plated-10
Universal and force-fitting connection of all profiles in a series Can be subsequently slid in the groove. Can be swivelled into the groove Can be retrofitted into an existing construction. Machining only on one profile
VB-3037
T- Matic Connector Set, bright zinc-plated-10
Extremely fast and flexible connection without machining mechansiche Universal and positive connection of all profiles in a series retrospectively in the groove moved. possible in an existing design retrofitting. Connector mounting only one profile,
